The Altiglo OHESU Heliport Radio Controller is an advanced remote activation system designed to provide pilots with convenient and reliable control of heliport lighting systems via VHF radio communication. The controller enables authorized aircraft to activate, deactivate, or adjust heliport lighting without the need for on-site personnel, enhancing operational efficiency and safety during night-time and low-visibility operations.
-
Acceptance Frequency: :
118–136 MHz (Factory default setting: 128.00 MHz)
-
Power Consumption: :
≤30W
-
Obstruction Light Intensity: :
Low Intensity 32 cd
-
Transmit Frequency: :
137–174 MHz / 400–470 MHz
-
Overall Dimensions: :
600 × 400 × 1300 mm
-
Wind Speed Resistance: :
80 m/s
-
Ambient Temperature: :
-40°C to +85°C
-
Working Humidity: :
0% – 95%
-
Power Consumption: :
20W
-
IP Rating: IP65 :
-20°C to +60°C
-
Material: :
Cold-Rolled Steel or Stainless Steel
-
Product Life Expectancy: :
Average 5 Years
-
Product Weight :
50 kg
-
Compliance Standards: :
ICAO / CAAC / FAA AC 150/5345-49 Type I & Type A
-
Rugged cold-rolled steel or SUS304 stainless steel enclosure designed for harsh outdoor environments.
-
Field-programmable operating frequency from 118 to 137 MHz in 25 kHz increments.
-
Industry-standard default frequency set to 128.00 MHz.
-
Configurable activation response with selectable click settings (default: 5 clicks, adjustable to 3 clicks)
-
Available in both AC and low-voltage DC power configurations..
-
Output overload and over-voltage protection safeguards connected lighting equipment. characteristics, making it ideal for radar-sensitive areas.
-
Integrated surge protection protects heliport lighting systems from electrical surges and lightning-related disturbances.
-
User-programmable activation duration of 15, 30, or 60 minutes with memory retention of the last selected setting.
-
Multiple control options including radio control, photocell operation, and manual on/off switching.
-
Built-in input transient protection for enhanced electrical reliability.
